Kenwood NXR-710K High Performance Repeater VHF 136-174 MHz 25-50W

This item includes:
Kenwood NXR-710K VHF Repeater

Item is in stock and usually ships same day if orders are place before 8pm Eastern Standard Time
Free Shipping on all orders over $1000
Expedited shipping available for additional cost
Shipping rates available in shopping cart
Product may be returned if unopened and unused within 7 days of purchase
Returns after 7 days or for products that demonstrate usage will not be accepted for returns but accepted as warranty repairs only

Frequency:

400-470

Watts:

50 Max

Channels:

Warranty:

36 Months

General data
Frequency range	VHF: 136 - 174MHz ; UHF1: 400 - 470MHz UHF2: 450-520MHz ; UHF3: 350 - 400MHz
Channel capacity	16
Channel spacing (analog)	12.5 / 20 / 25 kHz
Operating voltage	13.6 ± 15% V_DC
Max. power consumption (in stand by)	≤ 0.8 A
Max. power consumption (during transmission)	≤ 11 A
Frequency stability	±0.5 ppm
Antenna impedance	50 Ω
Duty Cycle	100%
Dimensions (H × W × D)	3.46 x 19 x 14.4 inches
Weight	18.74lbs

Transmitter
RF Power Output	5 – 50 W (adjustable)
FM Modulation (Analog Emissions Designator)	11K0F3E at 12.5 kHz 14K0F3E at 20 kHz 16K0F3E at 25 kHz
4FSK Digital Modulation (Digital Emissions Designator)	12.5 kHz (data only): 7K60FXD 12.5 kHz (data and voice): 7K60FXW
Conducted/Radiated Emission	-36 dBm < 1 GHz -30 dBm > 1 GHz
Modulation limiting	±2.5 kHz at 12.5 kHz ±4.0 kHz at 20 kHz ±5.0 kHz at 25 kHz
FM Hum & Noise	40 dB at 12.5 kHz 43 dB at 20 kHz 45 dB at 25 kHz
Adjacent Channel Power	60 dB at 12.5 kHz 70 dB at 20/25 kHz
Audio Response	+1 dB to -3 dB
Audio distortion	≤ 3 %
Digital vocoder type	AMBE++ or SELP
Digital Protocol	ETSI-TS102 361-1, 2 & 3

Receiver
Sensitivity (analog)	0.3 μV (12 dB SINAD) 0.22 μV (typical) (12 dB SINAD) 0.4 μV (20 dB SINAD)
Sensitivity (digital)	0.3 μV / BER 5%
Selectivity TIA-603 ETSI	65 dB at 12.5 kHz / 75 dB at 20 and 25 kHz 60 dB at 12.5 kHz / 70 dB at 20 and 25 kHz
Intermodulation TIA-603 ETSI	75 dB at 12.5/20/25 kHz 70 dB at 12.5/20/25 kHz
Spurious Response Rejection TIA-603 ETSI	80 dB at 12.5/20/25 kHz 80 dB at 12.5/20/25 kHz
S/N	40 dB at 12.5 kHz 43 dB at 20 kHz 45 dB at 25 kHz
Rated Audio Power Output	0.5 W
Rated Audio Distortion	≤ 3 %
Audio Response	+1 dB to -3 dB
Conducted Spurious Emission	< -57 dBm

Environmental Specs
Operating temperature range	-30 °C to +60 °C
Storage temperature range	-40 °C to +85 °C

User Manual:

Service Manual:

Programming Software:

TRY BEFORE YOU BUY DEMOS AVAILABLE

Kenwood NXR-710K

$2,565.20
